We have a new release of Terraform VMware Cloud Director Provider. Version 3.2.0 is now available, with some substantial improvements.
What’s New in Terraform VCD Provider 3.2.0
We have expanded support for NSX-T with four new resources and corresponding data sources:
vcd_network_routed_v2
for NSX-T and NSX-V routed networks.vcd_network_isolated_v2
for NSX-T and NSX-V isolated networks.vcd_nsxt_network_imported
for NSX-T imported networks.vcd_nsxt_network_dhcp
for NSX-T routed network DHCP configuration.
vcd_network_routed_v2
and vcd_network_isolated_v2
should be used for both NSX-V and NSX-T backed VDCs. Their older versions vcd_network_routed
and vcd_network_isolated
should only be used if DHCP pool configuration is required for NSX-V backed VDCs.
We also have a new resource and corresponding data source vcd_vm
which provides support for a standalone VM. It works with all the properties and attributes of vcd_vapp_vm
, with the difference that we can’t set a vapp_name
. The main benefit of this resource is that allows parallel creation and update of VMs. While creation of multiple VMs inside a vApp will be serialised, multiple standalone VMs are handled in parallel. As a quick example, the creation of 10 VMs within a vApp (18GB each) takes 21 minutes, while the corresponding creation of 10 standalone VMs takes less than 3 minutes.
1 2 3 4 5 6 7 8 9 10 11 12 13 |
1 vApp with 10 VMs with network bare VM ------------ ----------- Apply 21m 5.097s 12m 24.084s Destroy 5m 47.492s 4m 26.281s 10 standalone VM with network bare VM ------------ ----------- Apply 2m 58.690s 1m 31.818s Destroy 1m 15.381s 0m 40.361s |
You can quickly try the multiple VM creation with the trick below.
1 2 3 4 5 6 7 8 9 10 11 |
resource "vcd_vm" "TestMultiStandalone" { for_each = toset([ "one", "two", "three", "four", "five", "six", "seven", "eight", "nine", "ten"]) org = "datacloud" vdc = "vdc-datacloud" name = each.value catalog_name = "cat-datacloud" template_name = "photon-hw11" memory = 1024 cpus = 1 power_on = false } |
Let’s see a quick example of one the new network resources:
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 |
data "vcd_nsxt_edgegateway" "existing" { org = "datacloud" vdc = "nsxt-vdc-datacloud" name = "nsxt-gw-datacloud" } resource "vcd_network_routed_v2" "net_r_v2" { name = "net_r_v2" org = "datacloud" vdc = "nsxt-vdc-datacloud" edge_gateway_id = data.vcd_nsxt_edgegateway.existing.id gateway = "10.10.102.1" prefix_length = 24 static_ip_pool { start_address = "10.10.102.2" end_address = "10.10.102.200" } } |
In this configuration, we create a data source of a vcd_nsxt_edgegateway
. We need it to use its ID with the vcd_network_routed_v2
, which requires the edge gateway ID to be created. To add DHCP pools, we use a separate resource that refers to the network by ID, like in the example below.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 |
resource "vcd_nsxt_network_dhcp" "net_r_dhcp" { org = "datacloud" vdc = "nsxt-vdc-datacloud" org_network_id = vcd_network_routed_v2.net_r_v2.id pool { start_address = "10.10.102.210" end_address = "10.10.102.220" } pool { start_address = "10.10.102.230" end_address = "10.10.102.240" } } |
You can see all resources mentioned here used together at this example, which contains a standalone VM connected to three of the new network resources, with an additional vcd_nsxt_network_dhcp
that handles the DHCP settings of a vcd_network_routed_v2
.
Where can I get Terraform VCD Provider 3.2.0 from?
This 3.2.0 release is hosted in the Terraform registry and supports the latest Terraform 0.14 version.
Provider is available in the registry as of 3.0.0 release.
Documentation can be accessed on the site.
