Network Security

VMware NSX 3.2 Delivers New, Advanced Security Capabilities

It’s an impactful release focused on significant NSX Security enhancements

Putting a hard shell around a soft core is not a recipe for success in security, but somehow legacy security architectures for application protection have often looked exactly like that: a hard perimeter firewall layer for an application infrastructure that was fundamentally not built with security as a primary concern. VMware NSX Distributed Firewall pioneered the micro-segmentation concept for granular access controls for cloud applications with the initial launch of the product in 2013. The promise of Zero Trust security for applications, the simplicity of deployment of the solution, and the ease of achieving internal security objectives made NSX an instant success for security-sensitive customers.

Our newest release — NSX-T 3.2 — establishes a new marker for securing application infrastructure by introducing significant new features to identify and respond to malware and ransomware attacks in the network, to enhance user identification and L7 application identification capabilities, and, at the same time, to simplify deployment of the product for our customers.

“Modern day security teams need to secure mission-critical infrastructure from both external and internal attacks. By providing unprecedented threat visibility leveraging IDS, NTA, and Network Detection and Response (NDR) capabilities along with granular controls leveraging L4-L7 Firewall, IPS, and Malware Prevention capabilities, NSX 3.2 delivers an incredible security solution for our customers“

– Umesh Mahajan, SVP, GM (Networking and Security Business Unit)

This blog captures critical enhancements NSX-T 3.2 delivers from a security perspective. And stay tuned —we’ll follow up with more detailed blogs on each of these topics soon.

Distributed Advanced Threat Prevention (ATP)

Attackers often use multiple sophisticated techniques to penetrate the network, move laterally within the network in a stealthy manner, and exfiltrate critical data at an appropriate time. Micro-segmentation solutions focused solely on access control can reduce the attack surface — but cannot provide the detection and prevention technologies needed to thwart modern attacks. NSX-T 3.2 introduces several new capabilities focused on detection and prevention of attacks inside the network. Of critical note is that these advanced security solutions do not need network taps, separate monitoring networks, or agents inside each and every workload.

Distributed Malware Prevention

Lastline’s highly reputed dynamic malware technology is now integrated with NSX Distributed Firewall to deliver an industry-first Distributed Malware Prevention solution. Leveraging the integration with Lastline, a Distributed Firewall embedded within the hypervisor kernel can now identify both “known malicious” as well as “zero day” malware

Distributed Behavioral IDS

Whereas earlier versions of NSX Distributed IDPS (Intrusion Detection and Prevention System) delivered primarily signature-based detection of intrusions, NSX 3.2 introduces “behavioral” intrusion detection capabilities as well. Even if specific IDS signatures are not triggered, this capability helps customers know whether a workload is seeing any behavioral anomalies, like DNS tunneling or beaconing, for example, that could be a cause for concern.

Network Traffic Analysis (NTA)

For customers interested in baselining network-wide behavior and identifying anomalous behavior at the aggregated network level, NSX-T 3.2 introduces Distributed Network Traffic Analysis (NTA). Network-wide anomalies like lateral movement, suspicious RDP traffic, and malicious interactions with the Active Directory server, for example, can alert security teams about attacks underway and help them take quick remediation actions.

Network Detection and Response (NDR)

Alert overload, and resulting fatigue, is a real challenge among security teams. Leveraging advanced AI/ML techniques, the NSX-T 3.2 Network Detection and Response solution consolidates security IOCs from different detection systems like IDS, NTA, malware detection. etc., to provide a ”campaign view” that shows specific attacks in play at that point in time. MITRE ATT&CK visualization helps customers see the specific stage in the kill chain of individual attacks, and the ”time sequence” view helps understand the sequence of events that contributed to the attack on the network.

Key Firewall Enhancements

While delivering new Advanced Threat Prevention capabilities is one key emphasis for the NSX-T 3.2 release, providing meaningful enhancements for core firewalling capabilities is an equally critical area of innovation.

Distributed Firewall for VDS Switchports

While NSX-T has thus far supported workloads connected to both overlay-based N-VDS switchports as well as VLAN-based switchports, customers had to move the VLAN switchports from VDS to N-VDS before a Distributed Firewall could be enforced. With NSX-T 3.2, native VLAN DVPGs are supported as-is, without having to move to N-VDS. Effectively, Distributed Security can be achieved in a completely seamless manner without having to modify any networking constructs.

Distributed Firewall workflows in vCenter

With NSX-T 3.2, we are introducing the ability to create and modify Distributed Firewall rules natively within vCenter. For small- to medium-sized VMware customers, this feature simplifies the user experience by eliminating the need to leverage a separate NSX Manager interface.

Advanced User Identification for Distributed and Gateway Firewalls

NSX supported user identity-based access control in earlier releases. With NSX-T 3.2, we’re introducing the ability to directly connect to Microsoft Active Directory to support user identity mapping. In addition, for customers who do not use Active Directory for user authentication, NSX also supports VMware vRealize LogInsight as an additional method to carry out user identity mapping. This feature enhancement is applicable for both NSX Distributed Firewall as well as NSX Gateway Firewall.

Enhanced L7 Application Identification for Distributed and Gateway Firewalls

NSX supported Layer-7 application identification-based access control in earlier releases. With NSX-T 3.2, we are enhancing the signature set to about 750 applications. While several perimeter firewall vendors claim a larger set of Layer-7 application signatures, they focus mostly on internet application identification (like Facebook, for example). Our focus with NSX at this time is on internal applications hosted by enterprises. This feature enhancement is applicable for both NSX Distributed Firewall as well as Gateway Firewalls.

NSX Intelligence

NSX Intelligence is geared towards delivering unprecedented visibility for all application traffic inside the network and enabling customers to create micro-segmentation policies to reduce the attack surface. It has a processing pipeline that de-dups, aggregates, and correlates East-West traffic to deliver in-depth visibility.

Scalability enhancements for NSX Intelligence

As application infrastructure grows rapidly, it is vital that one’s security analytics platform can grow with it. With the new release, we have rearchitected the application platform upon which NSX Intelligence runs — moving from a stand-alone appliance to a containerized micro-service architecture powered by Kubernetes. This architectural change future-proofs the Intelligence data lake and allows us to eventually scale out our solution to n-node Kubernetes clusters.

Large Enterprise customers that need visibility for application traffic can confidently deploy NSX Intelligence and leverage the enhanced scale it supports.

NSX Gateway Firewall

While NSX Distributed Firewall focuses on east-west controls within the network, NSX Gateway Firewall is used for securing ingress and egress traffic into and out of a zone.

Gateway Firewall Malware Detection

NSX Gateway Firewall in the 3.2 release received significant Advanced Threat Detection capabilities. Gateway Firewall can now identify both known as well as zero-day malware ingressing or egressing the network. This new capability is based on the Gateway Firewall integration with Lastline’s highly reputed dynamic network sandbox technology.

Gateway Firewall URL Filtering

Internal users and applications reaching out to malicious websites is a huge security risk that must be addressed. In addition, enterprises need to limit internet access to comply with corporate internet usage policies. NSX Gateway Firewall in 3.2 introduces the capability to restrict access to internet sites. Access can be limited based on either the category the URL belongs to, or the “reputation” of the URL. The URL to category and reputation mapping is constantly updated by VMware so customer intent is enforced automatically even after many changes in the internet sites themselves.

With all these impactful new security capabilities we targeted for this release, it’s no wonder the internal code name for this project is “Impactor!” Be sure to comment below or Tweet us at @vmwareNSX to let us know which of the new NSX-T 3.2 security capabilities are valuable for you, and what additional features you want us to deliver in the future.

Learn more about NSX-T 3.2 here.
