Category Archives: Security

Automating a Multi-Action Security Workflow with VMware NSX

This post was written by VMware’s John Dias, (VCP-DCV), Sr. Systems Engineer, Cloud Management Solutions Engineering Team, and Hadar Freehling, Security & Compliance Systems Engineer Specialist

***

Through a joint effort with Hadar Freehling, one of my esteemed peers here at VMware, we co-developed a proof-of-concept workflow for a network security use case.  Hadar created a short video showing and explaining the use case, but in summary this is a workflow that reacts to and remediates a security issue flagged by third-party integration with VMware NSX. In the video, TrendMicro is used but it could be any other partner integration with vShield Endpoint.

Here’s what happens:

  • A virus is detected on a VM and is quarantined by the AV solution
  • The AV solution tags the VM with an NSX security tag
  • VMware NSX places the VM in a new Security Group, whose network policies steer all VM traffic through an intrusion prevention system (IPS)
  • vCenter Orchestrator (vCO) monitors the security group for changes and when a VM is added
    • a snapshot of the VM is taken for forensic purposes
    • a vSpan session (RSPAN) is set up on the Distributed Virtual Switch to begin capturing inbound/outbound traffic on the VM
    • once the VM has been removed from the security group, the vSpan session is removed

Watch the video below for a walk-through by Hadar:

You will note that there is a portion of the workflow that is handled natively by VMware NSX (Security Tag reaction, Security Group policy) but the snapshot and RSPAN are done via vCO workflow.

If you are interested in exploring this capability, I have provided the vCO workflow package for download. This is provided as-is and you should fully test it (and modify as needed) before using in your environment.

Assuming you have VMware NSX, vShield Endpoint and some third party integration already set up, you will need the following:

  • vCO 5.5.2
  • The NSX plugin for vCO (installed and configured)
  • The REST plugin with your NSX manager added as a REST host
  • vCenter plugin configured

The workflow package includes a good number of “helper” workflows which you will not need to run directly. The master workflow is in the root folder Security Reaction and is named “Set up VM Forensics RUN THIS” (just in case you had any doubt as to which one to run).

Multi-Site Security

The Security Reaction Master Workflow

Running the master workflow will prompt you for three items:

  • The NSX Security Group to monitor – This is why the NSX plugin is required, so that you can browse the vCO managed objects and locate the desired Security Group.
  • A time to sleep in seconds – The master workflow will run continuously until manually stopped and will use a REST call to NSX to get the current membership for the Security Group.  We have no recommendation on this poll time, although in testing we used 5-10 seconds.  It would have been better to use some external event to kick off the vCO workflow but we could not find a way to do this from NSX.  It may be possible to do via the partner solution, but we wanted this workflow package to be “partner neutral.”
  • Destination IPv4 address – This is the destination for the RSPAN (or vSpan session in vSphere API terms).  The vSpan session is created with some defaults (for example sampling rate, normal traffic allowed, etc).  If you want to change any of those properties, you will need to modify the Helper workflow named “Configure encapRemoteMirrorSource vSpan Session on DVS” (modify the “Create Port Mirror” script task).

Also note that this workflow doesn’t support VMs with multiple vNICs. Specifically, it will only create an RSPAN that includes the first vNIC found on a VM.  You can modify the Helper workflow “Implement Forensics” and adjust the script task “Prep for Mirror Creation” so that the additional NICs (if any) are added to the sourcePorts array. It’s something we intended to fix but forgot about until after our final testing and video production – so as they say in the textbooks “this is left as an exercise for the reader.”

Of course, there are many other actions that can be taken besides setting up an RSPAN and getting a snapshot. This solution can be extended to practically any task required during such an event such as creating a ticket in your service desk software, spinning up additional workloads to replace the compromised VM, sending emails, guest OS file system operations…all of these and more can be accomplished using vCO in conjunction with NSX.



A Customer Perspective: VMware NSX, Micro-Segmentation & Next-Generation Security

VMware NSX and Palo Alto Networks are transforming the data center by combining the Columbia-S12_WTR_MGHI_564fast provisioning of network and security services with next-generation security protection for East-West traffic. At VMworld, John Spiegel, Global IS Communications Manager for Columbia Sportswear will take the stage to discuss their architecture, their micro-segmentation use case and their experience. This is session SEC1977 taking place on Tuesday, Aug 26, 2:30-3:30 p.m.

Micro-segmentation is quickly emerging as one of the primary drivers for the adoption of NSX. Below, John shares Columbia’s security journey ahead of VMworld

+++++++++++++++++++++++++++++++++++++++

When I started at Columbia, we were about a $500 million company. Now we’re closing in on $2 billion and hoping to get to $3 billion rather quickly. So as you can imagine, our IT infrastructure has to scale with the business. In 2009, we embarked on a huge project to add a redundant data center for disaster recovery. As part of the project, we partnered with VMware and quickly created a nearly 100% virtualized datacenter.  It was a huge success. But something was missing; a security solution that matched our virtualized data center. There just wasn’t a great way to insert security in order to address east-west traffic between VMs, nor have the security tied to the applications as they moved around dynamically.

 We set out looking for a solution to bridge that gap.

To address our security needs in the data center, we looked at several different strategies and at that time, there really weren’t any good solutions. Many of the solutions were physical in nature. They required us to do some crazy configurations to apply security. We looked at the Cisco 6500 firewall blades, Juniper’s virtual solution and a few other lightweight security offerings, but they just didn’t have what we needed. The solutions at the time didn’t have what we needed. We kept looking.

At VMworld last year, we were introduced to VMware NSX. I saw the power of the platform, and it all started to click. And when Palo Alto Networks (our perimeter firewall vendor) announced they were a major partner, and that their technology integrated with NSX to give us an additional level of security, things really came together for us. The ability to drive security down into the infrastructure, down to the kernel level, and then take advantage of Palo Alto Networks next generation security was very attractive. Doing micro-segmentation with NSX, and then having the option of inserting next generation firewalling services from Palo Alto Networks in those areas of the business that require them, will really help us improve our overall security posture. A solution like this is where we need to be. These tools give us the ability to manage both physical and virtual security policies centrally with Palo Alto Networks management tool Panorama. I know that when workloads move the security and policies follow the workloads.

To me, that’s what it is about – advanced security inside the data center, plus automation via software that’s completely independent of the underlying physical infrastructure. With solutions such as NSX and the integration with Palo Alto Networks to provide advanced security services, we are going put security back in the data center, the right way.=

Jspiegel

John Spiegel
Columbia Sportswear



Micro-Segmentation: VMware NSX’s Killer Use Case

The advantages a software-defined data center, using network virtualization as a core underpinning, include service delivery speed, operational efficiency, reduced hardware dependency and lower cost. However, by far the most popular use case by customers thus far has been the use of NSX for network microsegmentation. Why? Because perimeter-centric network security has proven insufficient, and micro-segmentation has to date been operationally and economically infeasible. With NSX, security teams, in partnership with their network and virtualization teams, are benefiting from network micro-segmentation to begin to transform their data center security architecture. Then read the VMware SDDC Micro-Segmentation White Paper.

Rod

The Goldilocks Zone: Security In The Software-Defined Data Center Era

Last week, we spoke at the RSA Conference about a new concept in security – the Goldilocks zone.  With the help of Art Coviello, Executive Chairman of RSA, Chris Young, senior vice president and GM of Cisco’s Security business unit, and Lee Klarich, senior vice president of product management from Palo Alto Networks, we departed from the typical discussions about new controls or the latest threats.  We took the opportunity to lay out what we believe is a fundamental architectural issue holding back substantial progress in cyber security, and how virtualization may just provide the answer. The growing use of virtualization and the move towards software-defined data centers enable huge benefits in speed, scalability and agility; those benefits are undeniable. It may turn out, however, that one of virtualization’s biggest benefits is security. Continue reading

VMware at RSA Conference 2014 (#RSAC)

Summary:logo_rsac

  • Company outlines vision for security in the Software-Defined Data Center
  • Product and partner demonstrations in Booth #1615 to showcase growing security portfolio
  • New PCI-DSS 3.0 and FedRAMP reference architectures to be presented

Throughout its history, RSA Conference has consistently attracted the world’s best and brightest in the security field, creating opportunities for attendees to learn about IT security’s most important issues through first-hand interactions with peers, luminaries and emerging and established companies. Continue reading

VMware NSX is Off and Running In 2014

This afternoon, VMware announced Q4 2013 and FY2013 earnings. The results can be found here in our earnings press release. During the earnings call, we provided an update on VMware NSX momentum which we want to share with you.

In the fourth quarter, we delivered VMware NSX, our network virtualization platform, which we believe will do for networking what vSphere and server virtualization did for compute. The VMware NSX customers we highlighted for the fourth quarter are great examples of innovative companies that have made the architectural decision to deploy network virtualization and the Software-Defined Data Center as the heart of their data center strategies. They are virtualizing their networks to deliver the speed and agility they need today. These deals in the quarter included three of the top five investment banks, as well as several of the most respected enterprises and Telcos from around the world, including McKesson, Starbucks, Medtronic and China Telecom.

Additionally, this quarter we announced VMware and Palo Alto Networks will deliver a jointly-developed solution for network security. The integrated solution will enable customers to use the VMware NSX network virtualization platform to automate provisioning and distribution of Palo Alto Networks’ next-generation network security in their software-defined data centers. Side Note: if you are planning to attend the upcoming RSA Conference, read about our session which will take place on Monday, February 24 at 1pm titled, “The Goldilocks Zone: Security in the Era of the SDDC.”

Network virtualization with VMware NSX is a key enabler for the software-defined data center. In 2013, VMware took big steps to present a vision for the future of the data center and the transformation of the network. In 2014 we expect to see an accelerated pace of network virtualization adoption as companies move from consideration to decision on the software-defined data center, and we feel very strong in opportunity to capture this market transformation.

Chris King, VP Product Marketing

Networking & Security Business Unit

Network Security: The VMware NSX Network Virtualization Platform’s Hidden Gem

This week, we announced a new joint solution with our partner Palo Alto Networks that will

Best-In-Class Partners

automate and accelerate the deployment of next-generation network security with centralized management across physical and virtual domains. You can read the full announcement about the forthcoming integrated solution from our companies in our press release here.

For most data center operators, the idea of achieving the operational model of a VM for their data center networks is a top of mind benefit associated with the VMware NSX network virtualization platform. Through this model they can gain greater agility, efficiency and provisioning speed while reducing complexity as they implement a software-defined data center architecture. An often-overlooked feature set, fundamental to VMware NSX, is network security. Continue reading

VMware NSX, Convergence, and Reforming Operational Visibility for the SDDC

Through convergence, VMware NSX will substantially reform operational visibility for the era of the software-defined data center

Executive Summary

Since the launch at VMworld 2013, much of the discussion about VMware NSX has been focused on its core properties of agile and fully automated network provisioning; the ability to create fully functional L2-L7 virtual networks in a software container with equivalent speed and mobility of virtual machines.  And while these are very important capabilities of VMware NSX, we believe there is yet another and perhaps equally significant dimension to be discovered.  That is, how network virtualization and VMware NSX, through convergence and instrumentation of virtual networks, virtual compute, and the physical network, will substantially reform operational visibility for the era of the software defined data center.

With convergence comes new visibility

Convergence of network and compute is made possible by a platform ideally positioned at the first point in the architecture where these different yet closely related services can reliably coexist. A less obvious yet significant consequence of this is that convergence inherently provides more visibility, for the simple reason that a single platform now offers a consolidated and synchronous view into multiple services and how they relate to each other in real-time.  This combined visibility can bring about more sophisticated applications and operational tools than previously thought possible.

Consider the convergence of voice and data enabled by VoIP endpoints and call control software.  The combined visibility into the relationship between a data endpoint and a voice subscriber paved the way for services rich collaboration with multimedia, location, presence, and more.  This would arguably turn out to be the final preponderant outcome from voice/data convergence, when compared to the obvious initial benefits of infrastructure consolidation.

Similarly, network virtualization enabled by VMware NSX is the convergence of several different yet closely related virtualization services; virtual computing, virtual networks, and the physical network fabric.  The initial benefits of agile and automated network provisioning are obvious and significant.  However, once again, we will see that convergence enables a perhaps less obvious yet equally significant benefit through the combined visibility into these related services.  With network virtualization and VMware NSX, a single platform now has deep visibility into the application environment, the full L2-L7 network services consumed by the applications, and the physical network fabric on to which the services are transported.

VMware NSX converges virtual compute with virtual and physical networks

The ideal platform to enable this convergence and visibility is the hypervisor and its programmable software virtual switch.  The hypervisor is squarely positioned at the intersection of virtual machines (applications), virtual networks, the physical network, and storage access.  VMware NSX fully leverages this strategic position in the hypervisor.  And through centralized control software, NSX enables a single point to measure and view in aggregate the fluid relationship between individual applications, the L2-L7 networking services they consume, and the physical network.

As a simple example, consider an application with a tier of N virtual machines associated to a load balancing service.  From a single API, it would be possible to see the physical location of each VM, the physical location of their load balancer, measure and profile the traffic between the load balancer and each VM, detect and flag physical network connectivity problems between them, detect and flag misconfigurations on their virtual network ports, identify the instances affected, view the load and health of the load balancer instance, monitor the traffic with port counters and full packet captures, characterize all of this against a baseline or template, and expose this application specific view to the relevant application owners and network operators.  Comprehensive and targeted visibility helps you to extract more signal from the noise.

Troubleshooting

Physical network health heat map

Convergence also provides a better foundation for troubleshooting.  When one platform has visibility into multiple inter-dependent domains, this provides you a starting point to quickly identify the domain where a problem exists.  VMware NSX is ideally positioned in the hypervisor, at the critical intersection of two inter-dependent domains, the virtual and physical network.  VMware NSX has visibility into the health and state of the full L2-L7 virtual network.  Meanwhile, it’s constantly testing the health of the physical network (with tunnel health probes) between all of the hypervisor virtual switches and gateways, and made viewable in real-time through API queries and heat maps in NSX Manager.

For example, if a physical network issue is causing a connectivity problem, VMware NSX will be able to detect this right away and identify the affected hypervisors and virtual machines.  You’ve quickly identified the domain to troubleshoot (physical) and surveyed the scope of the problem with more actionable information to work with at the onset.  Conversely, what if a connectivity problem only existed in the virtual network, from perhaps a misconfigured ACL or firewall rule?  VMware NSX can identify right away that it’s not a physical network issue, and provides tools to inject and trace traffic through the virtual network (TraceFlow & Port Connections) to pinpoint the virtual switch and ACL dropping the traffic.

Centralized visibility of Blocked Flows in the virtual network

Blocked Flows monitoring in VMware NSX for vSphere

As an example (above), the Flow Monitoring tool provided in VMware NSX for vSphere provides a global view of all flows encountering firewall rules in the virtual network. In a troubleshooting scenario, we can see details (in real time or historically) about individual flows blocked anywhere in the virtual network, including application type, source and destination, time of day, and the specific rules involved.  This information is only a few clicks away at any time.

All of this actionable intelligence is made available through a single programmatic interface, the NSX API.  VMware has already extended existing operational tools to leverage the NSX API, such as with vCenter Operations Manager and Log Insight.  Meanwhile, partners are already integrating with NSX and extending their best of breed tools to visualize and correlate the virtual and physical network.  Let’s look at a couple of examples.

Visualize and correlate traffic flows from the virtual to physical network

With its position in the hypervisor, VMware NSX is directly adjacent to the applications in the virtual compute layer and has direct visibility into all of the flows.  Meanwhile, all of the flow data captured by NSX can be exported with standard interfaces (IPFIX) to a monitoring tool that can also collect standard flow data from the physical network, and correlate both into an aggregate view of virtual/physical flow visibility on any standard infrastructure hardware.

Virtual to Physical traffic flow visibility with Netflow Logic and Splunk

As an example, VMware NSX provides easy integration with NetFlow Logic, and Splunk (above), allowing you to visualize traffic as it flows through the virtual and physical network by simply aggregating and correlating standard IPFIX and Netflow export from VMware NSX and ToR switches.  You can view the Top Ten Talkers, select a traffic source and view the virtual network and physical path for that conversation.  For example (above), after picking a conversation we can see the virtual and physical details of that traffic such as the source VM IP address > source Hypervisor IP address > source ToR switch and ingress port > virtual network VXLAN ID > destination ToR switch and egress port  > destination Hypervisor IP address > destination VM IP address > Tx/Rx connection stats > Bandwidth utilized and time of day.

Visualize and correlate the physical and virtual network topology

VMware NSX knows the physical location of any virtual machine and the complete L2-L7 virtual network topology it’s attached to at all times.  NSX also provides standard SNMP interfaces into the operational state of the hypervisor and NSX appliance networking health and stats.  With this information easily accessible via the NSX API and SNMP, it’s pretty straightforward for physical network management tool to gain deeper visibility into the virtual network and it’s operational state.

Visualize and correlate the physical and virtual network topology with EMC Smarts

As an example, EMC Smarts integrates with the VMware NSX API and can combine and correlate the physical network topology with the VMware NSX virtual network topology and produce dependency maps.  For example (above), if a particular top of rack switch is experiencing and issue you can see a map of the tenant, applications, virtual networks, and hypervisors that would be affected.  As another example, this deep level of virtual/physical network visualization and correlation has also been developed by Riverbed in their Cascade solution.

Comprehensive dashboards and analytics with Log Insight

VMware NSX generates a lot of operational data, all of which can be exported through standard Syslog data, and accessible through the NSX API.  As an example, VMware Log Insight aggregates and analyzes machine data across multiple VMware platforms, now including VMware NSX (below).

VMware NSX operational data visibility with Log Insight

VMware NSX has tight integration with the existing VMware operational tools like vCenter Operations Manager (below) and Log Insight (above).  This provides capabilities such as performance analytics and real-time correlation of application processes, virtual machine and virtual network interface stats, physical network interface stats, network health, physical network flow logs, and predictive root cause analysis for complete operational visibility to diagnose issues quickly, across any standard network fabric.  We expect these powerful tools will be shared by both compute and network teams.

Comprehensive monitoring and root cause analysis with vCenter Operations Manager

VMware vCenter Operations Manager has also been extended to tap into the wealth of networking information accessible through the VMware NSX API.

Total virtual infrastructure visibility and root cause analysis with VMware vCOps

The built-in integration of VMware NSX into vCenter Operations Manager (above) coalesces networking visibility from NSX with the existing compute and storage operational data; forming one comprehensive tool for visibility and troubleshooting across the entire virtualization infrastructure.  For example, we can see things such as hypervisor CPU, storage, and networking health heat maps, dynamically learn normal thresholds, detect anomalies, drill down into granular metrics, and correlate events for root cause analysis.

With visibility and capability comes substantial reform

On its own the aggregate visibility enabled by VMware NSX is a significant win, but when combined with sophisticated capabilities at the hypervisor virtual switch layer, such as telemetry and L2-L7 network services, previously unthinkable tools can emerge that begin to reform the operational capabilities befitting to a software defined data center.  Meanwhile, existing monitoring tools (IPFIX, sFlow, ERSPAN, SNMP, Syslog) are extended to VMware NSX, gaining from the aggregate visibility gathered at the source (hypervisor vswitch); a more relevant position from which to measure and capture in a virtualized environment.

From packet inspection to deep application semantics

For decades packet header inspection has sufficed for “visibility” in the realm of network operations.  Maybe it’s a network switch inspecting packet headers to implement a security policy (ACL) or QoS, or an operator sifting through packet headers on a monitoring tool to identify traffic.  Either way, the policy and visibility is only as good as the rudimentary information contained in a packet header.  For example, we couldn’t tell whether or not traffic is coming from a legitimate application process, versus a rogue or anomalous process.  We wouldn’t know if traffic delivered to an instance was actually consumed by a healthy application process.  We couldn’t discern the user name, organization, application version, lifecycle (Dev/Test/Prod), and so on.  Packet header “visibility” in the physical network (by design) has never had any deep and meaningful insight into the application environment.

By contrast, through convergence of complete L2-L7 virtual networks, embedded with virtual compute at the hypervisor, VMware NSX has deep visibility into application semantics and metadata present at the virtual compute layer.

Application specific and Identity aware visibility (Activity Monitoring)

Application and Identity aware network activity monitoring with VMware NSX

VMware NSX for vSphere can monitor application relevant network activity down to the individual processes on a virtual machine sending or receiving traffic (above), user identity, organizational groups, application versions, ownership, operating systems, and so on.  For example, if you want to zero in on traffic going to a specific application process, destined for a specific set of machines, coming from a specific Active Directory group, you can do that.  Only a virtual networking platform deeply embedded with virtual compute can give you that kind of application relevant visibility with ease.  Monitoring is just the beginning.  This level of visibility could be used to create more sophisticated application templates, behavior profiles, and security policy.

While the application relevant visibility is certainly nice, sometimes you just want to take a quick look at any and all traffic a specific virtual machine is sending or receiving.  Of course packet header inspection is still a useful tool for this, and VMware NSX doesn’t necessitate any compromise.  In fact, with its position in the hypervisor, NSX can selectively analyze stateful traffic flows in real-time directly at the virtual network interface (vNic) for any virtual machine.

Real-time stateful flow monitoring directly at the virtual machine network interface (Live Flow)

Live Flow visibility per VM virtual NIC

For example, VMware NSX for vSphere provides a built-in tool, Live Flow monitoring (above), which allows you to simply pick any virtual machine’s network interface and see (in real-time) a summary of all flows and their state.  You can see a complete breakdown of all the flows at that VM, including the direction of each flow, the number of bytes and packets per flow, the firewall rule each flow was permitted through, IP addresses and port numbers, and the state of each connection.  There are no additional steps required.  There’s no need configure full packet captures to a remote tool and sifting through IP addresses looking for your VM.  For the simple task of targeted network traffic visibility, VMware NSX offers a simple tool.  You’re only a few clicks away from this information at any time.

When full packet captures are needed, you can selectively establish port mirroring directly from any VMs virtual network port to a remote monitoring system with SPAN/RSPAN/ERSPAN.  And for the situations where you want to capture packets from ports on the physical network, most monitoring tools now provide filters for VXLAN (such as Wireshark) that allow for easy decoding of the tunneled packets.

Security policy and compliance visibility

Of course there’s more to “visibility” than just looking at network traffic and trying to figure out what it is.  Troubleshooting is one of many important disciplines that can benefit from the comprehensive visibility provided by network virtualization. Consider for example the task of auditing security policy for compliance.  For this, VMware NSX for vSphere provides a central means to define and view real-time application security policy with a built-in tool called Service Composer.

Centralized real-time visibility into security policy and application isolation

Application security policy visibility with VMware NSX service composer

The Canvas view in Service Composer shows the security groups we’ve created, the objects in each group, and the services applied to each group such as stateful firewall isolation.  For example (above) we have a security group for PCI applications with a strict isolation policy from the IT applications, and we can see this by simply clicking on the firewall icon in our PCI container.  This isolation is enforced by the VMware NSX distributed kernel stateful firewall in the hypervisor and visible in real-time from a central view.

Looking ahead: Measurement, and Intelligent Optimization

With a solid foundation of capabilities, convergence, and visibility in the platform today, entirely enabled by software, we’re excited about what more is possible and the velocity at which we can enable them on any standard hardware or network architecture.

End-to-end Telemetry

An important tool to achieving maximum operational visibility is end-to-end measurement.  In addition to knowing the source and purpose of some application traffic, we might want to know the application performance profile and behavior over some period of time, accessible as a data point via the NSX API.  True end-to-end telemetry means you’re taking measurements as close to the data source as you can possibly get.  To that end, VMware NSX is ideally positioned at the source of traffic (deeply embedded in the virtual compute layer) and implements telemetry with flow-based virtual switches in the hypervisor.  Meaning, any conversation between any two endpoints can be accounted for, measured, and marked directly at the source and destination (hypervisor vswitch).

Network DRS

The VMware NSX virtual switch in the hypervisor is capable of L2-L4 network services in the kernel fast path.  Things like Layer 2 switching, Layer 3 routing, east-west stateful firewalling, ACL, QoS, can all be locally processed within the hypervisor kernel at x86 machine speeds.  Combined with the aforementioned application awareness and end-to-end telemetry, we have all of the information and capabilities needed to intelligently optimize the placement of workloads to obtain the best possible performance for your applications.

Network DRS: network aware optimal workload placement

For example, consider a multi-tier application where end-to-end telemetry has measured significant traffic between two VMs on tiers separated by Layer 3 routing and firewall security.  With that information, the virtual compute layer can decide to migrate the two VMs on to the same hypervisor for the benefit of optimized performance and removing that traffic from the physical network.  Optimal placement trumps optimal path.

Consider another scenario where physical network connectivity issues create problems between a given set of hypervisors.  Remember that VMware NSX is constantly testing the health of the physical network and can not only discover the problem quickly but also identify the affected hypervisors, network services, and virtual machines.  While the physical network issue is being addressed, the virtual compute layer could decide to leverage this intelligence and proactively migrate the affected virtual machines to other unaffected hypervisors.  End-to-end telemetry could later validate if the action actually helped or not.

Elephant flow detection and response

Another example of Network DRS is the scenario where end-to-end telemetry in the VMware NSX flow-based hypervisor virtual switch can detect and profile certain flows as “Elephants” – those long lived bulky flows that unwittingly step all over the short lived yet precious “Mice”.  With so many potential flows to look at in aggregate, VMware NSX is ideally positioned to distribute this telemetry across the hypervisor virtual switches.  Each hypervisor virtual switch measures its own slice of local traffic.  Once the Elephants have been spotted they can be tagged and dealt with, such as migrating them away from the precious Mice, and applying QoS markings for visibility and policy in the network fabric.

Visibility on your choice of hardware, cloud, and hypervisor

Of course everything we’ve discussed here is enabled by a software platform, VMware NSX, designed to work on any network hardware, with any hypervisor, provisioned through any cloud portal, and supporting any application.  Through hardware-agnostic software, both the operational visibility and capability of the tools remain consistent and normalized across the variations of hardware and network architectures throughout the infrastructure lifecycle.

More to come

VMware NSX is generally available today (yay!) with solid integration to operational tools from VMware and our partners.  In the big picture, we think this is only scratching the surface in terms of what VMware NSX is capable of in reforming operational tools for the SDDC.  Meanwhile, we continue to get excellent feedback from our customers that will help to shape this platform and the future of networking.  It’s going to be a fun ride.  I hope you’ll join us. :-)

Cheers,

Brad Hedlund
Engineering Architect
VMware NSBU

Special thanks to: Rod Stuhlmuller, Manish Mittal, Chris King, T. Sridhar



Networking and Security Session Guide for VMworld 2013

So, you’re a network geek, security ninja or cloud architect and you’re wondering what to attend at VMworld 2013. Well, here’s your handy guide to the sessions at this year’s conference in San Francisco you will be most interested in..

This year we have a full agenda of networking and security track sessions. We recognize that there may be overlap in times and many of these sessions will be repeated so make sure you check the schedule builder to catch any repeats.

Monday August 26, 2013
Networking Track
Session ID Session Title Times Audience
NET5529 VMware NSX: A Customer’s Perspective 2:00 – 3:00 pm Cloud Architect
VI / Network Admin
NET5847 NSX: Introducing the World to VMware NSX 2:30 – 3:30 pm Cloud Architect
VI / Network Admin
NET5716 Advanced VMware NSX Architecture 5:00 – 6:00 pm Cloud Architect
VI / Network Admin
Security
SEC5893 Changing the Economics of Firewall Services in the Software-Defined Center – VMware NSX Distributed Firewall 11:00 – 12:00 pm Firewall Architect
Security Architect
SEC5428 VMware Compliance Reference Architecture Framework Overview 11:00 – 12:00 pm Security Admin
Security Architect
SEC5749 Introducing NSX Service Composer:  The New Consumption Model for Security Services in the SDDC 5:00 – 6:00 pm Security Admin
Security Architect
Tuesday Aug 27, 2013
Networking Track
Session ID Session Title Times Audience
NET5266 Bringing Network Virtualization to VMware environments with NSX 11:00 – 12:00 pm VI / Network Admin
NET5184 Designing Your Next Generation Datacenter for Network Virtualization 11:30 – 12:30 pm Cloud Architect
NET7388-S Network Virtualization: Moving Beyond the Obvious 12:30 – 1:30 pm Cloud Architect
NET5270 Virtualized Network Services Model with VMware NSX 12:30 – 1:30 pm VI / Network Admin
NET5516 An Introduction to Network Virtualization 12:30 –  1:30 pm Cloud Architect
NET5521 vSphere Distributed Switch -  Design and Best Practices 2:00 – 3:00 pm Cloud Architect
NET5584 Deploying VMware NSX Network Virtualization 2:00 – 3:00 pm VI / Network Admin
NET5796 Virtualization and Cloud Concepts for Network Administrators 3:30 – 4:30 pm Network Admin
NET5716 Advanced VMware NSX Architecture 3:30 – 6:00 pm Cloud Architect
VI / Network Admin
NET5525 Real-world Deployment Scenarios for VMware NSX 5:00 – 6:00 pm Cloud Architect
NET5790 Operational Best Practices for VMware NSX 5:00 – 6:00 pm VI / Network Admin
Security
SEC5318 NSX Security Solutions In Action – Deploying, Troubleshooting, and Monitoring for VMware NSX Service Composer 11:00 – 12:00 pm Security Admin
Security Architect
SEC5755 VMware NSX with Next-Generation Security by Palo Alto Networks 1:00 – 2:00 pm Firewall Architect
SEC5253 Get on with Business – VMware Reference Architectures Help Streamline Compliance Efforts 3:30 – 4:30 pm Security Architect
SEC5891 Technical Deep Dive: Build a Collapsed DMZ Architecture for Optimal Scale and Performance Based on NSX Firewall Services 3:30 – 4:30 pm Firewall Architect
SEC5775 NSX PCI Reference Architecture Workshop Session 1 – Segmentation 3:30 – 4:30 pm Security Architect
Wednesday, August 28, 2013
Networking Track
Session ID Session Title Time Audience
NET5520 VMware NSX Integration with OpenStack 11:00 – noon Cloud Architect
NET5522 VMware NSX Extensibility: Network and Security Services from 3rd party vendors 8:00 – 9:00 am Cloud Architect
NET5654 Troubleshooting VXLAN and Network Services in a Virtualized Environment 9:30 – 10:30 am VI / Network Admin
Security Track
SEC5624 VMware Compliance Reference Architecture Framework: Accelerate your Deployments 8:30 – 9:30 am Security Architect – Panel Discussion
SEC5828 Datacenter Transformation with Network Virtualization: Today and Tomorrow 9:30 – 10:30 am Cloud Architect, VI /Network Admin
SEC5750 Security Automation Workflows with NSX 10:00 – 11:00 am Security Architect
SEC5889 Troubleshooting and Monitoring NSX Service Composer (and Partner) Policies 1:00 – 2:00 pm Firewall Admin
SEC5820 NSX PCI Reference Architecture Workshop Session 2 – Privileged User Control 2:30 – 3:30 pm Security Architect
SEC5894 Deploying, Troubleshooting, and Monitoring VMware NSX Distributed Firewall 4:00 – 5:00 pm Firewall Admin
SEC5847 NSX PCI Reference Architecture Workshop Session 3 – Operational Efficiencies 4:00 – 5:00 pm Security Architect
Thursday, August 29, 2013
Networking and Security Tracks
Session ID Session Title Time Audience
NET5520 VMware NSX Integration with OpenStack 11:00  – noon Cloud Architect
NET5522 VMware NSX Extensibility: Network and Security Services from 3rd party vendors 8:00 – 9:00 am Cloud Architect
SEC5582 Multi-site Deployments with Network Virtualization 12:30 – 1:30 pm Cloud Architect

Hands-on Labs @VMworld 2013

The team has built some great lab exercises to see Networking and Security in action:Hands-on Labs @VMworld 2013

  • HOL-SDC-1302: vSphere Distributed Switch from A to Z
  • HOL-SDC-1303: VMware NSX Network Virtualization Platform for VMware environments
  • HOL-SDC-1319 – VMware NSX Network Virtualization Platform

Hope you have a great event. Follow us at @VMwareNSX and let us know if you want to come by and meet us at the booth.

See you in San Francisco.

The VMware Team

What is a Distributed Firewall?

In the post “What is Network Virtualization?” I described a model where the application’s complete L2-L7 virtual network is decoupled from hardware and moved into a software abstraction layer for the express purpose of automation and business agility. In this post I’ll focus on network security, and describe an imminent firewall form factor enabled by Network Virtualization — the Distributed Firewall.

ALL YOUR PACKET ARE BELONG TO US

If InfoSec ruled the world … well, OK, maybe not the world … if InfoSec ruled the data center network design, and if money was no object, we would probably have something like this. Every server in the data center directly connected to its own port on one massive firewall. Every packet sent from every server would be inspected against a stateful security policy before going anywhere. And every packet received by every server would pass one final policy check before hitting the server’s NIC receive buffer. The firewall wouldn’t care about the IP address of the servers, for the simple reason that it’s directly connected to every server. E.g. “The server on this port can talk to the server on that port, on TCP port X”. And if that wasn’t good enough, the firewall knows everything about the servers connected to it, and can create rules around a rich set of semantics. All of this with no performance penalty. That would be awesome, right? Continue reading
